电信行业/通讯市场用柴油发电机组Telecom generators
Telecom generators
It is an intelligent system that integrates power generation, control, electronics, and communication technologies, with high reliability, stability, and intelligent management capabilities. It is the "silent guardian" of modern communication networks, directly related to the quality and survival ability of communication networks.
Chinese manufacturer of communication generator sets
A high reliability backup power system specifically designed for the communication industry, such as mobile base stations, data centers, fiber optic relay stations, etc. The main function is to provide continuous, stable, and reliable power supply for communication equipment during power outages, ensuring uninterrupted operation of the communication network.
-
Main application scenarios of communication generator sets
Mobile communication base station: the primary or backup power supply for 2G/3G/4G/5G base stations.
Data center/cloud server room: As a backup of the UPS (uninterruptible power supply) system, it starts before the mains power fails and the UPS battery runs out, bearing all loads.
Fiber optic relay station/transmission node: ensures signal amplification and transmission of long-distance communication fiber optic cables.
Satellite ground stations, radio and television stations, emergency communication vehicles, etc.
-
Key points for selecting communication generator sets
When choosing a communication generator set, it is important to consider:
Power: Calculate the total power of all equipment in the base station (main equipment, transmission equipment, air conditioning, etc.) and leave a margin of 10% -20%. The future demand for 5G expansion also needs to be considered.
Brand and configuration: Choose reliable engine, generator, and controller brands.
Mute level: Select a suitable level of noise for the soundproof speaker based on the environmental requirements of the base station location.
Intelligent monitoring: Ensure that the controller's functionality meets remote monitoring requirements.
Supplier service: Choose a supplier that can provide fast installation, debugging, and after-sales maintenance services.
Common problems and solutions for communication generator sets
1、 What are the reasons for the slow and weak start-up of communication generator sets? How should we handle it?
Possible reasons:
Insufficient/damaged battery power; Corrosion/looseness of battery terminals; Starting motor/relay malfunction
Handling method:
Step 1: Check if there is any display on the control panel. If there is no display, check the main power supply and fuse.
Step 2: Check the battery voltage (no load should be higher than 12V, 24V system should be higher than 24V). If the voltage is too low, charge or replace it.
Step 3: Tighten the battery terminals and remove oxides.
Step 4: Check if the emergency stop button has been reset.
Step 5: If the above is correct, professional personnel need to check the starting relay and starting motor.
2、What are the reasons for immediately shutting down a communication generator set after starting? How should we handle it?
Possible reasons:
Fuel depletion: the most easily overlooked reason.
Oil circuit blockage: dirty and clogged fuel filter, unopened oil circuit valve, bent inlet pipe.
There is air in the oil circuit: it has not been emptied after replacing the filter, or there are leakage points in the pipeline.
Handling method:
Step 1: Confirm the fuel tank level!
Step 2: Check if all fuel valves are in the open position.
Step 3: Manually pump the oil, check if the fuel is smooth, and empty the air in the oil circuit (loosen the air release screw of the filter or high-pressure pump, pump the oil until diesel without bubbles flows out).
Step 4: Replace the fuel filter.
